PART NO. |
THREAD |
TUBE O.D. |
DIMENSIONS |
MPa |
|||||||
|
E |
|
D1 |
D2 |
B |
D |
I1 |
L1 |
S1 |
S2 |
||
|
1CW-12-06 |
M12X1.5 |
|
6 |
6 |
7 |
10 |
7 |
22 |
12 |
14 |
31.5 Light series L |
|
1CW-14-08 |
M14X1.5 |
|
8 |
8 |
8 |
12 |
8 |
23 |
14 |
17 |
|
|
1CW-16-10 |
M16X1.5 |
|
10 |
10 |
8 |
14 |
9 |
24 |
17 |
19 |
|
|
1CW-18-12 |
M18X1.5 |
|
12 |
12 |
8 |
16 |
10 |
25 |
19 |
22 |
|
|
1CW-22-15 |
M22X1.5 |
|
15 |
15 |
10 |
19 |
11 |
26 |
22 |
27 |
|
|
1CW-26-18 |
M26X1.5 |
|
18 |
18 |
10 |
22 |
11.5 |
28 |
27 |
32 |
|
|
1CW-26-22 |
M26X1.5 |
|
18 |
22 |
10 |
27 |
13.5 |
28 |
27 |
32 |
16 Light series L |
|
1CW-30-22 |
M30X2 |
|
22 |
22 |
12 |
27 |
13.5 |
30 |
32 |
36 |
|
|
1CW-30-25 |
M30X2 |
|
22 |
25 |
12 |
31 |
13.5 |
30 |
32 |
36 |
|
|
1CW-36-28 |
M36X2 |
|
28 |
28 |
12 |
32 |
16.5 |
33 |
38 |
41 |
|
|
1CW-45-35 |
M45X2 |
|
35 |
35 |
14 |
40 |
14.5 |
36 |
46 |
50 |
|
|
1CW-52-42 |
M52X2 |
|
42 |
42 |
16 |
46 |
16 |
39 |
55 |
60 |
|
|
1DW-14-06 |
M14X1.5 |
|
6 |
6 |
7 |
11 |
11 |
26 |
14 |
17 |
63 Heavy series S |
|
1DW-16-08 |
M16X1.5 |
|
8 |
8 |
8 |
13 |
13 |
28 |
17 |
19 |
|
|
1DW-18-10 |
M18X1.5 |
|
10 |
10 |
8 |
15 |
12.5 |
29 |
19 |
22 |
|
|
1DW-20-12 |
M20X1.5 |
|
12 |
12 |
10 |
17 |
14.5 |
31 |
22 |
24 |
|
|
1DW-22-14 |
M22X1.5 |
|
14 |
14 |
10 |
19 |
16 |
34 |
24 |
27 |
|
|
1DW-24-16 |
M24X1.5 |
|
16 |
16 |
10 |
21 |
15.5 |
34 |
27 |
30 |
40 Heavy series S |
|
1DW-30-20 |
M30X2 |
|
20 |
20 |
12 |
26 |
17.5 |
39 |
32 |
36 |
|
|
1DW-36-25 |
M36X2 |
|
25 |
25 |
12 |
31 |
20 |
44 |
41 |
46 |
|
|
1DW-42-30 |
M42X2 |
|
30 |
30 |
14 |
36 |
20.5 |
47 |
46 |
50 |
|
|
1DW-52-38 |
M52X2 |
|
38 |
38 |
16 |
44 |
23 |
54 |
55 |
60 |
31.5Heavy seriesS |
|
Note:In case if you are interested to order the adapter in complete set with cutting ring and nut,it is necessary to insert suffix “RN” after our part NO.,for example 1DW-20-12RN. |
|||||||||||
