PART NO. |
THREAD |
FLANGE SIZE |
TUBE O.D. |
DIMENSIONS |
MPa |
|||||
|
d1 |
I |
I1 |
L1 |
S1 |
S2 |
|||||
|
1CFL-22-08 |
M22X1.5 |
1/2” |
15 |
30.2 |
6.73 |
41 |
56 |
24 |
27 |
31.5 Light series L |
|
1CFL-26-12 |
M26X1.5 |
3/4" |
18 |
38.1 |
6.73 |
45.5 |
62 |
30 |
32 |
|
|
1CFL-30-12 |
M30X2 |
3/4" |
22 |
38.1 |
6.73 |
45.5 |
62 |
32 |
36 |
16 Light series L |
|
1CFL-36-16 |
M36X2 |
1" |
28 |
44.4 |
8 |
46.5 |
63 |
38 |
41 |
|
|
1CFL-45-20 |
M45X2 |
1.1/4” |
35 |
50.8 |
8 |
47.5 |
69 |
41 |
50 |
|
|
1CFL-52-24 |
M52X2 |
1.1/2” |
42 |
60.3 |
8 |
53 |
76 |
46 |
60 |
|
|
1DFS-24-08 |
M24X1.5 |
1/2" |
16 |
31.7 |
7.8 |
44.5 |
63 |
24 |
30 |
40 Heavy series S |
|
1DFS-24-12 |
M24X1.5 |
3/4" |
16 |
41.3 |
8.8 |
50.5 |
69 |
30 |
30 |
|
|
1DFS-30-12 |
M30X2 |
3/4" |
20 |
41.3 |
8.8 |
50.5 |
72 |
30 |
36 |
|
|
1DFS-36-12 |
M36X2 |
3/4" |
25 |
41.3 |
8.8 |
51 |
75 |
30 |
46 |
|
|
1DFS-36-16 |
M36X2 |
1" |
25 |
47.6 |
9.5 |
60 |
81 |
36 |
46 |
|
|
1DFS-42-16 |
M42X2 |
1" |
30 |
47.6 |
9.5 |
60.5 |
87 |
36 |
50 |
|
|
1DFS-42-20 |
M42X2 |
1.1/4" |
30 |
54 |
10.3 |
65.5 |
92 |
41 |
50 |
|
|
1DFS-52-20 |
M52X2 |
1.1/4" |
38 |
54 |
10.3 |
67 |
98 |
46 |
60 |
31.5Heavy seriesS |
|
1DFS-52-24 |
M52X2 |
1.1/2" |
38 |
63.5 |
12.6 |
73 |
104 |
46 |
60 |
|
|
Note:ln case if you are interested to order the adapter in complete set with cutting ring and nut,it is necessary to insert
suffix"RN"after our part NO.,for example 1DFS-52-24RN.
|
||||||||||
