PART NO.

THREAD

O-RING

DIMENSIONS

E

F

Fend

A

B

L

S1

1JO-04-02

7/16"X20

5/16"X24

O902

14

7.54

27.5

14

1JO-04-03

7/16"X20

3/8"X24

O903

14

7.54

27.5

14

1JO-04

7/16"X20

7/16"X20

O904

14

9.14

29

14

1JO-04-05

7/16"X20

1/2"X20

O905

14

9.14

29

17

1JO-04-06

7/16"X20

9/16"X18

O906

14

9.93

30

17

1JO-04-08

7/16"X20

3/4"X16

O908

14

11.13

33

22

1JO-05

1/2"X20

1/2"X20

O905

14

9.14

29

17

1JO-05-04

1/2"X20

7/16"X20

O904

14

9.14

29

14

1JO-05-06

1/2"X20

9/16"X18

O906

14

9.93

30

17

1JO-05-08

1/2"X20

3/4"X16

O908

14

11.13

33

22

1JO-06

9/16"X18

9/16"X18

O906

14.1

9.93

30

17

1JO-06-04

9/16"X18

7/16"X20

O904

14.1

9.14

29

17

1JO-06-05

9/16"X18

1/2"X20

O905

14.1

9.14

29.5

17

1JO-06-08

9/16"X18

3/4"X16

O908

14.1

11.13

33

22

1JO-06-10

9/16"X18

7/8"X14

O910

14.1

12.7

37

27

1JO-06-12

9/16"X18

1.1/16"X12

O912

14.1

15.09

40

32

1JO-08

3/4"X16

3/4"X16

O908

16.7

11.13

36

22

1JO-08-04

3/4"X16

7/16"X20

O904

16.7

9.14

34

22

1JO-08-06

3/4"X16

9/16"X18

O906

16.7

9.93

35

22

1JO-08-10

3/4"X16

7/8"X14

O910

16.7

12.7

40

27

1JO-08-12

3/4"X16

1.1/16"X12

O912

16.7

15.09

43

32

1JO-08-14

3/4"X16

1.3/16"X12

O914

16.7

15.09

43

36

1JO-10

7/8"X14

7/8"X14

O910

19.3

12.7

42.5

27

1JO-10-08

7/8"X14

3/4"X16

O908

19.3

11.13

39

24

1JO-10-12

7/8"X14

1.1/16"X12

O912

19.3

15.09

45.5

32

1JO-10-14

7/8"X14

1.3/16"X12

O914

19.3

15.09

45.5

36

1JO-12

1.1/16"X12

1.1/16"X12

O912

21.9

15.09

48

32

1JO-12-08

1.1/16"X12

3/4"X16

O908

21.9

11.13

43

30

1JO-12-10

1.1/16"X12

7/8"X14

O910

21.9

12.7

45

30

1JO-12-14

1.1/16"X12

1.3/16"X12

O914

21.9

15.09

48

36

1JO-12-16

1.1/16"X12

1.5/16"X12

O916

21.9

15.09

48

38

1JO-14

1.3/16"X12

1.3/16"X12

O914

22.6

15.09

48.5

36

1JO-14-12

1.3/16"X12

1.1/16"X12

O912

22.6

15.09

48.5

32

1JO-14-16

1.3/16"X12

1.5/16"X12

O916

22.6

15.09

50.5

38

1JO-16

1.5/16"X12

1.5/16"X12

O916

23.1

15.09

49

38

1JO-16-12

1.5/16"X12

1.1/16"X12

O912

23.1

15.09

49

36

JO-16-14

1.5/16"X12

1.3/16"X12

O914

23.1

15.09

49

36

1JO-16-20

1.5/16"X12

1.5/8"X12

O920

23.1

15.09

53

50

1JO-20

1.5/8"X12

1.5/8"X12

O920

24.3

15.09

54.5

50

1JO-20-16

1.5/8"X12

1.5/16"X12

O916

24.3

15.09

52.5

46

1JO-20-24

1.5/8"X12

1.7/8"X12

O924

24.3

15.09

54.5

55

1JO-24

1.7/8"X12

1.7/8"X12

O924

27.5

15.09

57.5

55

1JO-24-20

1.7/8"X12

1.5/8"X12

O920

27.5

15.09

57.5

50

1JO-24-32

1.7/8"X12

2.1/2"X12

O932

27.5

15.09

59.5

70

1JO-32

2.1/2"X12

2.1/2"X12

O932

33.9

15.09

66

70

Note:Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
