PART NO. |
THREAD |
O-RING |
DIMENSIONS |
||||||
|
E |
F |
|
F |
A |
B |
S1 |
S2 |
|
|
|
1J09-04-030G |
7/16"X20 |
3/8"X24 |
|
O903 |
24.5 |
28 |
11 |
14 |
|
|
1JO9-04OG |
7/16"X20 |
7/16"X20 |
|
O904 |
24.5 |
27.2 |
11 |
17 |
|
|
1J09-04-050G |
7/16"X20 |
1/2"X20 |
|
O905 |
26.6 |
29.9 |
14 |
17 |
|
|
1J09-04-060G |
7/16"X20 |
9/16"X18 |
|
O906 |
26.6 |
31.8 |
14 |
19 |
|
|
1J09-05-040G |
1/2"X20 |
7/16"X20 |
|
O904 |
26.6 |
30 |
14 |
17 |
|
|
1JO9-05OG |
1/2"X20 |
1/2"X20 |
|
O905 |
26.6 |
29 |
14 |
17 |
|
|
1J09-05-060G |
1/2"X20 |
9/16"X18 |
|
O906 |
26.6 |
31.8 |
14 |
19 |
|
|
1J09-06-040G |
9/16"X18 |
7/16"X20 |
|
O904 |
26.9 |
30 |
14 |
17 |
|
|
1J09-06-050G |
9/16"X18 |
1/2"X20 |
|
O905 |
26.9 |
29.9 |
14 |
17 |
|
|
1JO9-06OG |
9/16"X18 |
9/16"X18 |
|
O906 |
26.9 |
31.8 |
14 |
19 |
|
|
1J09-06-080G |
9/16"X18 |
3/4"X16 |
|
O908 |
30 |
36.8 |
19 |
24 |
|
|
1J09-08-040G |
3/4"X16 |
7/16"X20 |
|
O904 |
32 |
33 |
19 |
17 |
|
|
1J09-08-060G |
3/4"X16 |
9/16"X18 |
|
O906 |
33 |
33.5 |
19 |
19 |
|
|
1JO9-08OG |
3/4"X16 |
3/4"X16 |
|
O908 |
33 |
36.8 |
19 |
24 |
|
|
1J09-08-100G |
3/4"X16 |
7/8"X14 |
|
O910 |
34.8 |
44 |
22 |
27 |
|
|
1JO9-08-12OG |
3/4"X16 |
1.1/16"X12 |
|
O912 |
37.9 |
51 |
27 |
32 |
|
|
1J09-10-080G |
7/8"X14 |
3/4"X16 |
|
O908 |
38 |
40 |
22 |
27 |
|
|
1JO9-10OG |
7/8"X14 |
7/8"X14 |
|
O910 |
37.8 |
44 |
22 |
27 |
|
|
1JO9-10-12OG |
7/8"X14 |
1.1/16"X12 |
|
O912 |
41 |
51 |
27 |
32 |
|
|
1JO9-12-08OG |
1.1/16"X12 |
3/4"X16 |
|
O908 |
45 |
44 |
27 |
24 |
|
|
1JO9-12-10OG |
1.1/16"X12 |
7/8"X14 |
|
O910 |
44.2 |
47 |
27 |
27 |
|
|
1J09-120G |
1_1/16"X12 |
1.1/16"X12 |
|
O912 |
44.2 |
51 |
27 |
32 |
|
|
1J09-12-160G |
1.1/16"X12 |
1.5/16"X12 |
|
O916 |
47.8 |
54.5 |
33 |
41 |
|
|
1J09-140G |
1.3/16"X12 |
1.3/16"X12 |
|
O914 |
47.5 |
53 |
30 |
36 |
|
|
1J09-14-160G |
1.3/16"X12 |
1.5/16"X12 |
|
O916 |
48.5 |
54.5 |
33 |
41 |
|
|
1J09-16-120G |
1.5/16"X12 |
1.1/16"X12 |
|
O912 |
48.8 |
54.5 |
33 |
32 |
|
|
1J09-16-140G |
1.5/16"X12 |
1.3/16"X12 |
|
O914 |
49 |
56 |
33 |
36 |
|
|
1J09-160G |
1.5/16MX12 |
1.5/16"X12 |
|
O916 |
48.8 |
54.5 |
33 |
41 |
|
|
1JO9-16-20OG |
1.5/16"X12 |
1.5/8"X12 |
|
O920 |
53.8 |
59 |
41 |
50 |
|
|
1JO9-20-16OG |
1.5/8"X12 |
1.5/16"X12 |
|
O916 |
55.5 |
59.5 |
41 |
41 |
|
|
1JO9-20OG |
1.5/8"X12 |
1.5/8"X12 |
|
O920 |
55.3 |
59 |
41 |
50 |
|
|
1JO9-20-24OG |
1.5/8"X12 |
1.7/8"X12 |
|
O924 |
59.4 |
63 |
48 |
55 |
|
|
1J09-240G |
1.7/8"X12 |
1.7/8"X12 |
|
O924 |
62.5 |
63 |
48 |
55 |
|
|
1J09-320G |
2.1/2"X12 |
2.1/2"X12 |
|
O932 |
80 |
76 |
63 |
70 |
|
|
Note:1 .Nut and sleeve should be ordered separately. The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube. 2.F end is connected with IS011926-1 port. |
|||||||||
