PART NO. |
THREAD E |
HOSE BORE |
DIMENSIONS |
||||
|
DN |
DASH |
A |
C |
H |
S2 |
||
|
22691-02-03 |
G1/8"X28 |
5 |
03 |
26.5 |
5.5 |
31.5 |
14 |
|
22691-02-04 |
G1/8"X28 |
6 |
04 |
30 |
5.5 |
34.5 |
14 |
|
22691-04-03 |
G1/4"X19 |
5 |
03 |
26.5 |
5.5 |
33.5 |
19 |
|
22691-04-04 |
G1/4"X19 |
6 |
04 |
30 |
5.5 |
36.5 |
19 |
|
22691-04-05 |
G1/4"X19 |
8 |
05 |
33 |
5.5 |
39.5 |
19 |
|
22691-04-06 |
G1/4"X19 |
10 |
06 |
30 |
5.5 |
36.5 |
19 |
|
22691-06-04 |
G3/8"X19 |
6 |
04 |
30 |
6.3 |
37.7 |
22 |
|
22691-06-05 |
G3/8"X19 |
8 |
05 |
33 |
6.3 |
40.7 |
22 |
|
22691-06-06 |
G3/8"X19 |
10 |
06 |
35.3 |
6.3 |
43 |
22 |
|
22691-08-06T |
G1/2"X14 |
10 |
06 |
35.3 |
7 |
43.3 |
27 |
|
22691-08-08 |
G1/2"X14 |
12 |
08 |
41 |
7.5 |
51 |
27 |
|
22691-08-10 |
G1/2"X14 |
16 |
10 |
56.5 |
7.5 |
55.5 |
27 |
|
22691-10-08 |
G5/8"X14 |
12 |
08 |
41 |
9.5 |
51.5 |
30 |
|
22691-10-10 |
G5/8"X14 |
16 |
10 |
56.5 |
9.5 |
56 |
30 |
|
22691-12-08T |
G3/4"X14 |
12 |
08 |
41 |
10.9 |
52.1 |
32 |
|
22691-12-10 |
G3/4"X14 |
16 |
10 |
56.5 |
10.9 |
56.6 |
32 |
|
22691-12-12 |
G3/4"X14 |
20 |
12 |
65.5 |
10.9 |
66 |
32 |
|
22691-16-12T |
G1"X11 |
20 |
12 |
65.5 |
11.7 |
68.3 |
41 |
|
22691-16-14 |
G1"X11 |
22 |
14 |
71.2 |
11.7 |
69.3 |
41 |
|
22691-16-16 |
G1"X11 |
25 |
16 |
76.7 |
11.7 |
73.8 |
41 |
|
22691-20-16T |
G1.1/4"X11 |
25 |
16 |
78 |
11 |
69.5 |
50 |
|
22691-20-20W |
G1.1/4"X11 |
32 |
20 |
91.5 |
11 |
84.3 |
50 |
|
22691-24-24W |
G1.1/2"X11 |
40 |
24 |
109.4 |
13 |
103 |
55 |
|
22691-32-32W |
G2"X11 |
50 |
32 |
131.8 |
16 |
123.3 |
70 |
|
Note: 1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 22692-xx-xx. |
|||||||
