PART NO. |
THREAD E |
HOSE BORE |
DIMENSIONS |
||||
|
DN |
DASH |
A |
C |
H |
S2 |
||
|
26741-04-03 |
7/16"X20 |
5 |
03 |
37.6 |
9 |
17.2 |
15 |
|
26741-04-04 |
7/16"X20 |
6 |
04 |
40.2 |
9 |
18.1 |
15 |
|
26741-05-04 |
1/2 "X20 |
6 |
04 |
40.5 |
9.5 |
18.5 |
17 |
|
26741-05-05 |
1/2"X20 |
8 |
05 |
42.7 |
9.5 |
19.3 |
17 |
|
26741-05-06 |
1/2"X20 |
10 |
06 |
44.6 |
9.5 |
20.3 |
17 |
|
26741-06-04 |
9/16"X18 |
6 |
04 |
40.5 |
10.5 |
18.5 |
19 |
|
26741-06-05 |
9/16"X18 |
8 |
05 |
42.7 |
10.5 |
19.3 |
19 |
|
26741-06-06 |
9/16"X18 |
10 |
06 |
44.3 |
10.5 |
20 |
19 |
|
26741-06-08 |
9/16"X18 |
12 |
08 |
56.8 |
10.5 |
21.9 |
19 |
|
26741-08-06 |
3/4"X16 |
10 |
06 |
45.7 |
11 |
21.4 |
24 |
|
26741-08-08 |
3/4"X16 |
12 |
08 |
58.6 |
11 |
23.5 |
24 |
|
26741-10-08 |
7/8"X14 |
12 |
08 |
58.9 |
13 |
24 |
27 |
|
26741-10-10 |
7/8"X14 |
16 |
10 |
70.1 |
13 |
25.3 |
27 |
|
26741-10-12 |
7/8"X14 |
20 |
12 |
77 |
13 |
28.9 |
27 |
|
26741-12-08 |
1.1/16"X12 |
12 |
08 |
60 |
15 |
25 |
32 |
|
26741-12-10 |
1.1/16"X12 |
16 |
10 |
71.2 |
15 |
26.4 |
32 |
|
26741-12-12 |
1.1/16"X12 |
20 |
12 |
77.4 |
15 |
30 |
32 |
|
26741-12-16 |
1.1/16"X12 |
25 |
16 |
85.3 |
15 |
31 |
32 |
|
26741-14-12 |
1.3/16"X12 |
20 |
12 |
77.4 |
15 |
30 |
36 |
|
26741-16-12 |
1.5/16"X12 |
20 |
12 |
77.4 |
16 |
30 |
41 |
|
26741-16-16 |
1.5/16"X12 |
25 |
16 |
85.7 |
16 |
31.5 |
41 |
|
26741-16-20 |
1.5/16"X12 |
32 |
20 |
96.3 |
16 |
35.5 |
41 |
|
26741-20-20W |
1.5/8"X12 |
32 |
20 |
96.6 |
17 |
35.9 |
50 |
|
26741-24-20W |
1.7/8"X12 |
32 |
20 |
100.8 |
20 |
40.1 |
55 |
|
26741-24-24W |
1.7/8"X12 |
40 |
24 |
114.8 |
20 |
44.1 |
55 |
|
26741-32-32W |
2.1/2"X12 |
50 |
32 |
135.9 |
23.5 |
51.6 |
75 |
|
Note: 1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 26742-xx-xx. |
|||||||
