PART NO. |
THREAD |
CAPTIVE |
DIMENSIONS |
|||||
|
E |
F |
|
F end |
A |
B |
L |
S1 |
|
|
1B-04WD |
G1/4"X19 |
G1/4"X19 |
|
WD-B04 |
12 |
12 |
32 |
19 |
|
1B-04-06WD |
G1/4"X19 |
G3/8"X19 |
|
WD-B06 |
12 |
12 |
34.5 |
22 |
|
1B-04-08WD |
G1/4"X19 |
G1/2"X14 |
|
WD-B08 |
12 |
14 |
39 |
27 |
|
1B-06WD |
G3/8"X19 |
G3/8"X19 |
|
WD-B06 |
13.5 |
12 |
34 |
22 |
|
1B-06-08WD |
G3/8"X19 |
G1/2"X14 |
|
WD-B08 |
13.5 |
14 |
40.5 |
27 |
|
1B-08WD |
G1/2"X14 |
G1/2"X14 |
|
WD-B08 |
16 |
14 |
43 |
27 |
|
1B-08-12WD |
G1/2"X14 |
G3/4"X14 |
|
WD-B12 |
16 |
16 |
46 |
32 |
|
1B-12WD |
G3/4"X14 |
G3/4"X14 |
|
WD-B12 |
18.5 |
16 |
46.5 |
32 |
|
1B-12-16WD |
G3/4"X14 |
G1"X11 |
|
WD-B16 |
18.5 |
18 |
52.5 |
41 |
|
1B-16WD |
G1"X11 |
G1"X11 |
|
WD-B16 |
20.5 |
18 |
54.5 |
41 |
|
1B-16-20WD |
G1"X11 |
G1.1/4"X11 |
|
WD-B20 |
20.5 |
20 |
58.5 |
50 |
|
1B-20WD |
G1.1/4"X11 |
G1.1/4"X11 |
|
WD-B20 |
20.5 |
20 |
58.5 |
50 |
