PART NO. |
THREAD |
|
DIMENSIONS |
|||||||
E |
F |
G |
|
|
A |
B |
C |
S1 |
S2 |
|
BB-02 |
G1/8"X28 |
G1/8"X28 |
G1/8”X28 |
|
|
19.8 |
5.5 |
19.8 |
11 |
14 |
BB-04 |
G1/4"X19 |
G1/4"X19 |
G1/4”X19 |
|
|
24.5 |
5.5 |
24.5 |
14 |
19 |
BB-06 |
G3/8"X19 |
G3/8"X19 |
G3/8”X19 |
|
|
27.5 |
6.3 |
27.5 |
16 |
22 |
BB-08 |
G1/2"X14 |
G1/2"X14 |
G1/2”X14 |
|
|
34.5 |
7.5 |
34.5 |
22 |
27 |
BB-12 |
G3/4"X14 |
G3/4"X14 |
G3/4"X14 |
|
|
40 |
10.9 |
40 |
27 |
32 |
BB-16 |
G1"X11 |
G1"X11 |
G1"X11 |
|
|
46 |
11.7 |
46 |
33 |
41 |
BB-20 |
G1.1/4"X11 |
G1.1/4"X11 |
G1.1/4"X11 |
|
|
50.5 |
11 |
50.5 |
41 |
50 |
BB-24 |
G1.1/2"X11 |
G1.1/2"X11 |
G1.1/2"X11 |
|
|
57.5 |
13 |
57.5 |
48 |
55 |
BB-32 |
G2"X11 |
G2"X11 |
G2"X11 |
|
|
72.5 |
16 |
72.5 |
63 |
70 |
